jiangsu boda Sell cnc cutting drilling & mil

CNC cutting & drilling machine technical specifications 1. Machine tools technical specifications Heavy-duty steel gantry beams Heavy pre-tighten linear guide structure High-strength steel plate clamping stuff support High-speed drilling principal spindle head Unified cutting & drilling complex control systems, automatic conversion of drilling & cutting High-precision, high-speed plasma cutting device 2. Drilling machines principal spindle technical specifications Principal spindle taper hole: BT50 drilling maximum diameter 40 Principal spindle Speed: Auto speed varying, high accuracy positioning Principal spindle power: 15KW frequency conversion Principal spindle feed: High-power AC servo-driven, ball bearing transmit the leading screw 3. Plasma devices technical specifications Plasma generator: different models are possible according to the specific requirements of the user Initial positioning: resistance contacting positioning type Height controller: Automatic arc voltage height controller 4. Matching devices Automatic Tool Change Mechanism Tool length compensation measurement system Drilling stroke automatic measuring device Dust exhaust device, smoke and dust filter
